12 Volt 4 Amp Power Supply PLC Case , Switch Mode Power Supply High Efficiency For Magnetic Powder Brake

Wu Han Micro Control Electric Co., Ltd.
Contact Now

12 Volt 4 Amp Power Supply PLC Case , Switch Mode Power Supply High Efficiency For Magnetic Powder Brake

  • 1
  • 2
  • 3

Brand Name : True Engin

Model Number : PSM24V

Certification : ISO9001

Place of Origin : China,Hubei

MOQ : 1 UNIT

Price : Negotiate

Payment Terms : T/T, L/C, Western Union

Supply Ability : 10000UNITS/MONTH

Delivery Time : 1~3 DAYS

Packaging Details : CARTON

Power Supply : DC24V/4A

Case : PLC Case

Output Voltage : 24V

Warranty : 2 years

Lead time : 2 days

Payment Term : 100% in advance

Contact Now

12 Volt 4 Amp Power Supply PLC Case , Switch Mode Power Supply High Efficiency For Magnetic Powder Brake

12 Volt 4 Amp Power Supply PLC Case , Switch Mode Power Supply High Efficiency For Magnetic Powder Brake



Output Current 4 A Constant Current Power Supply With PLC Case For Magnetic Clutch



Brief Introduction



PSM 24V constant current/constant voltage power supply is the first PLC module constant current/voltage power supply, exquisite and high precision, easy to operate, strict protection, with following specification:



Exclusive Siemens shape and interface



No fans, high efficiency



Exclusive over current, short-circuit protection, military quality.



Exclusive voltage current double circuit, control is more stability, higher precision, good operation.



  PSM 24 V constant current source

Iten No. Output Voltage Output power Maximum Output Current

PSM24V_4A_CC 0-4A 80W 22V

PSM24V_3A_CC 0-3A 60W 22V

PSM24V_2A_CC 0-2A 40W 22V

PSM24V_1A_CC 0-1A 20W 22V



Packing and delivery



1. Neutral carton packing
2. One piece in one carton box
3. Normally one controller with two loadcells,this is easy for shipping.
4. One unit shipping
5. Lead time:within 3 days



15V GND 5V GND       PE 24V GND PAN PAN   PA PA



Auxiliary voltage         power input   Output the   Output
  output           cathode   positive





Control model



External analog input control



a.Analog control input 0-5 V, insert jumper cap to "5 V".



b.Analog control input input 0-1 0 V, insert jumper cap to 1 0 "V".



c.Analog control input 0-2 0 m A, insert the jumper cap to "2 0 m A". d.Analog control input 0-2 V, insert jumper cap to "P n".



12 Volt 4 Amp Power Supply PLC Case , Switch Mode Power Supply High Efficiency For Magnetic Powder Brake12 Volt 4 Amp Power Supply PLC Case , Switch Mode Power Supply High Efficiency For Magnetic Powder Brake12 Volt 4 Amp Power Supply PLC Case , Switch Mode Power Supply High Efficiency For Magnetic Powder Brake
